System Versa CXV8 Toggle 2-STG (Alloy) with Ground Spreader and Bag

Compare
  • Compact, uncompromised performance.
  • 75mm ball levelling.
  • Perfect for payloads to 0-12kg (26.4bs).
  • 15+0 selectable counterbalance positions.
  • Ergonomically located CB Plus switch.
  • 5+0 selectable positions of fluid pan and tilt drag.
  • Positive selection radial ring controls.
  • 2-stage fast toggle adjustment legs.
  • Durable black anodised alloy tubing.
  • Comes with on ground spreader.
  • Comes with 2-stage tripod bag.
  • 3 year warranty.
From your nearest dealer

Introducing the Versa CXV8 Toggle 2-Stage (Alloy) Tripod System – The Ultimate Cinematic and Documentary Companion

Unlock your filmmaking potential with the 4097 Versa CXV8 Toggle 2-Stage (Alloy) Tripod System, a powerhouse combination of the Versa CXV8 fluid head and the rugged 420G Toggle tripod, complete with a ground spreader. This exceptional tripod system is tailor-made for cinematic and documentary projects, where the ever-shifting payload and centre of gravity demand precision and versatility.

The Versa CXV8, the crown jewel of the 75mm ball levelling CompassX series, stands as a testament to professional-grade camera support. Engineered to accommodate camera rigs weighing from 0kg to 12kg, it boasts an impressive array of features, including the innovative CB Plus 16 balance positions and five levels of fluid drag adjustment. With the Versa CXV8, you’re stepping into a world of unmatched stability and adaptability.

Paired seamlessly with the 2-stage Toggle (alloy) tripod and enhanced by the ground spreader, this tripod system is a game-changer. Experience a substantial height range spanning from 570mm to 1740mm (22.4-68.5″), ensuring you capture every angle with precision. The positive toggle leg locks guarantee fast and secure setup, while the ground spreader delivers unwavering stability in any shooting environment.

Elevate your filmmaking to new heights with the Versa CXV8 Toggle 2-Stage (Alloy) Tripod System – the ultimate tool for professionals who demand nothing but the best.

Specifications - System Versa CXV8 Toggle 2-STG (Alloy) with Ground Spreader and Bag

Camera Platform

Quick release

Components

1141: Versa CXV8 fluid head, 420G: Toggle 75 2-stage tripod (alloy), 411: On ground spreader, 679: Pan handle – fixed with clamp, 1520: Shoulder strap (Aircell), 3514: Softcase 2-stage

Counterbalance Positions

16 selectable positions (15+0)

Height Above Bowl

176mm (6.9")

Height Range

570-1740mm (22.4-68.5")

Illuminated Controls

Bubble Level

Leg Extension

2-stage

Leg Material

Alloy

Lock Type

Toggle

Mounting Base

Ø75mm (2.9") ball levelling

Pan Handle

Fixed length 390mm (15.4")

Pan Range

360°

Pan Tilt Drag

5 selectable fluid drag positions + 0

Pan Tilt Locks

Positive lock caliper brake system

Payload Range

0-12kg (0-26.4lbs)

Sliding Range

100mm (3.93")

Temperature Range

-40° to +65°C (-40° to +150°F)

Tilt Range

+ 90°/ -75°

Transport Length

861mm (33.9")

Weight

6.9kg (15.2lbs)

Compatible Accessories

EAN | UPC | GTIN 9354041003867
